PERFECT CONTROL OF YOUR MATERIALS MANAGEMENT

The warehouse management software enables perfect control of your material flows. ESAlogistics supports the management of your raw materials and finished products from goods acceptance to production replenishment, storage and picking through to loading. Special attention is paid here to batch traceability and the shelf life of goods.


Material flow management - ESAmfm

Integrated in ESAweight Manager, the material flow manager is the central control element for all transport tasks. It allows logistical goods movements to be controlled and monitored transparently from the point of origin to the destination.

transfer orders are triggered  by freely definable strategies and control:

•    Driverless transport systems (FTS/APM)
•    High-bay warehouses (HLR)
•    Automatic conveyor systems for small-parts warehouses
•    User-guided stock movements via handheld or stacker terminals

Your solution for manually preparing raw materials or commissioning


This station contains all components to  identify products by means of a scanner, to weigh manually down to each single gram and save data for gapless tracebility.

By using energyoptimised modules, an integrated functioning of at least 18 hrs without any recharging is guaranteed. This functioning can be prolongued up to 36 hrs by using a battery pack. According to the safety class IP65 all components are manufactured of stainless. This dosing station is equipped with an Industry-PC-System and is connected with the main station via WLan.

FUNCTIONS

• Stainless steel weighin station: weighing up to 60kg in steps of 5g
• Platform size: 720x480mm
• Safety class IP65
• 12˝ touchscreen PC-system / Operating system Windows
• Swivel-monted touchscreen
• Data connectivity to main board by WLAN
• Measures*) H: 110cm | L: 130cm | B: 56cm (*depending on construction)
• One internal battery: weight 72 kg , operating time 18 hrs.
• Two internal batteries: weight 78,5 kg, operating time 36 hrs.
• Charge time: 12 A: 2 Std | 4 A: 5 Std.

Process Automation in manageable stages

Become faster, increase quality and still remain flexible. Process automation in manageable, perfectly coordinated stages. Achieve a substantial increase in your productivity!

ESAweight is our modularly structured process control system, which has been developed precisely to meet the needs of production facilities in the bulk materials industry. ESAweight is configured for the processes of your production facility and your entire flow of goods. It can be extended modularly at any time in line with your growth. Furthermore, we cover many elements of a traditional Manufacturing Execution System (MES), such as production management - also across different locations - or comprehensive recording of operating data. This means that you only need ESAweight as a single system between the plant controller and your ERP system. This reduces the complexity of your systems many times over.

•     Control and monitoring of batch processes (batch control)
•     Processing of solid and liquid substances
•     Data exchange with ERP system
•     Integration of automated storage systems and driverless transport systems
•     Overall Equipment Effectiveness - OEE figures for increasing overall efficiency
